Brand:
QuicklyItem no.:
FDWIR20221019Product origin:
ChinaColor:
Gold ReflectorLead Time:
5-7daysLithium batteries,as the main energy source of new energy vehicles,its quality requirements are getting higher and higher.The pole piece coating process of lithium battery is an important process in lithium battery production, which includes mixing, coating, drying, rolling, cutting and other processes.In the coating process,the baking and molding of the slurry is a very important part.If the temperature is not uniform and the response is not timely,it is easy to cause quality problems in the subsequent coating of the pole piece,such as insufficient adhesion, scorched or unbaked, and substandard density,which will seriously affect the pole piece performance.Drying the paste on the metal foils is not trivial, but with the help of infrared lamp for coating,it can be accelerated considerably！
1.Product Description
Quartz IR Emitters Halogen Infrared Heater Lamp Tube for Electrode Coating Heating Process of Lithium Batteries
Quickly manufactures fast response medium wave infrared lamp in virtually any length,Wattage,and Voltage combination for industrial heating systems and new applications or direct replacement into existing equipment.Nomatter what kind of IR Replacement Emitters you need,just contact us and get customized products.
Advantages with infrared heaters.
23*11mm / 33*15mm Twin Tube Fast Medium Wave Infrared Lamp with different filament configurations can be made with single side cable connection or two sides, and different heating channels. this allows extraordinary flexibility both in terms of heated area modularity and cable position. In the picture below there are some of the most common filament configurations:
2.Industrial Applications
| Food industry | food drying, food heating, food packaging material molding, food high temperature sterilization; |
| Printing industry | drying and curing of glue and ink; |
| Glass industry | annealing of glass and drying of coatings; |
| Packaging industry | PET blowing, laminating, ink drying; |
| Footwear industry | activated drying of glue; |
| Furniture industry | rapid drying of waterborne/oily coatings and paints; |
| Rubber industry | surface modification, softening and molding of plastics; |
| Photovoltaic industry | battery wafer soldering, sintering, substrate drying, spray preheating; |
| Automotive industry | sunlight simulation environment warehouse, sealing strip / wire harness heating, vehicle painting paint, body part point to make baking;Bonding Automotive Interiors |
| Textile industry | dry coating, fabric preheating, drying, pressing and activation of adhesives. |
3.ABOUT US
Anhui Quickly Industrial Heating Technology Co., ltd is a family of privately-owned companies focused on the development of infrared heating technology for more than 14 years which dramatically reduces the time and space required for industrial heating and drying processes and provides quantum leaps forward in efficiencies for our global customers.We manufactures quality quartz infrared heating element for many businesses' equipment.
4.Why Choose US
Our Halogen Infrared Lamps are under standard in CE & ROHS, we have strict quality control to make sure each IR lamp is perfect!By the way,we support the best service for you:
A:Sample Service
Some samples are free of charge, buyer shoulder the fright cost.
B:Customized Service
1. All of our Infrared Drying Elements are customized according to your unique practical request, professional technicians do one-to-one service for you and can customize 1pc Infrared Heater for your quality testing at the beginning.
2. We offer OEM services, we can print your logo on Infrared heating lamps as your requirements.
C:After-sale Service
Warranty Time of Short wave Infrared heat lamp: 5,000 hours
Warranty Time of Carbon Fiber Infrared heat lamp: 10,000 hours
Warranty Time of Medium wave Infrared heat lamp: 20,000 hours
During the warranty time, any non-man-made quality issue, once confirmed, we will sent the new replacement immediately without any charge.
5.Shipping & Packing
6.FAQ
1. Are you a factory or trading company?
Quickly is a factory, we are professional manufacturer of infrared heater for more than 10 years.
2. Where is your factory? Can I visit your factory?
We're in Hefei city,Anhui Province of China. You are warmly welcome to our factory, we will be happy to show you our production, QC, warehouse, etc.
3. Can I have samples? Is it free?
Yes, we are happy to offer samples for you to check and test. Depends on sample quantity and product model, we will
confirm with you whether it's free sample or not.
4. What is your term of delivery?
We accept FOB, CIF, EXW etc. Please choose the one which is the most convenient and cost effective for you.
5. What about the lead time for mass production?
It depends on the order quantity and the season you place the order. Generally speaking, the lead time of MOQ is about
7-15 days. We suggest that you start inquiry at least two months before the date you would like to get the products at your country.
6. Do you offer guarantee for the products?
Yes, it must be. We guarantee 2 years for heaters and 5000-8000 hours for infraraed heater.
7. What type of payment do you accept?
T/T.WEST UNION.PAYPAL.CREDIT CARD.
8. Is it OK to print my logo on product?
Yes, it's possible. But please kindly note we have MOQ request for different products.
9. Can you do the design for us?
Yes. We have a professional team having good experience in box design and manufacturing. Just tell us your idea and
we will help to carry out your ideas into perfect packing boxes. It does not matter if you do not have someone to complete
files. Send us high resolution images, your logo and text and tell us how you would like to arrange them. We will send you
finished files for confirmation.
Fast response medium wave infrared emitters are heaters that fall between the short and standard medium-wave. Utilizing the best of both wavelength. Response times as fast as short wave, with a maximum power output of 120 kW/m2 and lengths up to 4 meters. The heaters is suitable for drying processes because of transferring heat at a medium wave spectrum (2-4micron) .
view more
Fast medium wave infrared heaters can design twin tube IR emitters with different filament configurations such as single side connection cable and two sides connection cable, one heating channel and two heating channels. The Max. length is up to 4.0 meters and all the fast medium wave IR heat lamps can be fixed white ceramic or gold reflector directly on the quartz tube.
view more
Fast response medium wave infrared emitters have same product processing as short wave infrared lamps, made up from coiled tungsten filament and surrounded by a quartz glass and kinds of halogen gas. It belongs to vacuum lamp. It can be made into single round tube and twin tubes based on the working situation.
view more
Fast Medium Wave Infrared Heating Lamp is mainly used in the longitudinal stretching process section in BOPET film production.In order to achieve the high light transmittance and the process requirements of raising the temperature to 100℃ within 5s,fast medium wave infrared emitters are best choice as its fall between the short and standard medium-wave. Utilizing the best of both wavelength. Response times as fast as short wave, with a maximum power output of 120 kW/m2 and lengths up to 4 meters.
view more
No matter what material your screen printing on or how many color applications you need, infrared heat is the ideal heat to dry your screen printing for a variety of reasons, including: IR heats only the surface, minimizing potential damage to your products. It can be targeted exactly. Infrared heat is ‘instant on,’ reaching the desired temperature almost instantly. There’s no cool-down period either. Infrared drying systems can be set up with both conveyor belts for mass production and for flash drying handling one unit at a time. Infrared heat uses less energy than other heating methods.
view more
Twin tube IR emitter is made up of 8-shape high-purity clear quartz twin tube, each tube has Heating Coil of Tungsten material which runs in U shape in the tube which is filled with halogen gas.Power Density up to 150KW/m2 is achieved. Heating up and cooling down time is approximately one second. There are two standard sizes 11 mm x 23 mm and 15 mm x 33 mm in cross section for twin tube short wave IR radiators, and the maximum length available is 4000 mm
view more
Twin tube infrared lamp is made up of 8-shape high-purity clear quartz twin tube, each tube has Heating Coil of Tungsten material which runs in U shape in the tube which is filled with halogen gas.
view more
Infrared heating is a kind of radiation heating. It spreads by a kind of infrared radiation (light)-- infrared light from material in the form of molecular (atomic) resonance absorption, so as to achieve the purpose of heating. It can be applied in many fields such as the heating process of industry coating, plastic forming, automotive industry, glass making, spinning, solar PV, food baking, drying of printing inks, quick drying of primer and paint on furniture, printed circuit, and so forth.
view more
